Overview

The Tissue-Tek Xpress® x120 enables fast and continuous tissue processing, delivering standardized, high-quality results that are compatible with IHC and molecular pathology techniques.

The Tissue-Tek Xpress® x120 enables fast and continuous tissue processing, delivering standardized, high-quality results that are compatible with IHC and molecular pathology techniques.

Features:

Continuous magazine loading every 20 minutes
The x Series are pre-programmed with two rapid protocols: standard and extended
The x Series reagents are prepackaged in containers that are placed directly onto the instrument
Tissue-Tek Xpress proprietary reagents are formalin- and xylene-free

Benefits:

Provides a steady flow of processed tissues for embedding
Enables continuous, rapid processing of both biopsy and larger tissue
Makes exchanging reagents fast, simple, and error-free by eliminating reagent dilution, pouring, or placement mistakes
Allows for a greener work environment by eliminating exposure to harsh chemicals and reducing waste

Workflow Benefit:

Work in a standardized way for high-quality processed tissue
The Xpress x120 allows continuous loading, streamlining your laboratory's workflow
Fast processing and shorter turnaround times—compatible with IHC and molecular pathology
Enables same-day diagnosis, helping reduce patient stay and anxiety

Need assistance?

Get in Touch

Specifications

Product name	Tissue-Tek Xpress^® x120 Rapid Tissue Processor
Product code	7720
Application	Continuous rapid processing of human or animal tissue for routine clinical and research histology
Power requirement	Single phase, 200 VAC ± 10%, 50/60 Hz, 15 A (NEMA L6-20 dedicated receptacle)
Dimensions (W× D × H)	170 × 71 × 162 cm (67 × 28 × 64 in.)
Weight	465 kg (1,023 lb)
Retorts	Load station—1 station Retorts—4 retorts Unload stations—2 stations
Capacity	Up to 40 cassettes, every 20 minutes
Processing programs	Standard up to 2mm; 60 minutes or Extended up to 3mm; 120 minutes
Temperature ranges	Processing stations #1 and #2: 51° C ± 1° C (123.8 °F ± 1.8 °F) Processing stations #3 and #4: 65° C ± 2° C (149 °F ± 3.6 °F)
Certifications	Complies with: UL 61010-1: 2nd Ed.: 2004, CAN/CSA-C22.2 No. 61010-1: 2nd Ed.: 2004, CAN/CSA-C22.2 No. 61010-2-010:04, IEC61010-2-010: 2003 CAN/CSA-C22.2 No. 61010-2-081:04, IEC61010-2-081: 2001 CAN/CSA-C22.2 No. 61010-2-101: 04, IEC61010-2-101: 2002 FDA Registration (Regulation No. 864.3875) FDA Certified with ETL evaluation
Regulatory status	IVD, FDA Class I

Consumables

Product Code	Product Name
7720	Tissue-Tek Xpress^® x120 Rapid Tissue Processor
7103	Tissue-Tek Xpress^® 40-Cassette Basket with Handle and Lid
7104	Tissue-Tek Xpress^® 40-Cassette Basket Lid
7106	Tissue-Tek Xpress^® Tray Liners; 100/case
7107	Tissue-Tek Xpress^® x120 Fume Filter; 2/case
7115	Tissue-Tek Xpress^® Pre-Processing Solution; 4 × 3.8 L/case
7117*	Tissue-Tek Xpress^® Pre-Processing Fixative; 4 × 3.8 L/case
7120*	Tissue-Tek Xpress^® Molecular Fixative; 4 × 3.8 L/case
7730	Tissue-Tek Xpress^® x120 Processing Reagent Set
7760	Tissue-Tek Xpress^® x50 Processing Reagent Set
7011	x120, Uninterrupted Power Supply (1.5 hours)
4800	Tissue-Tek^® Accu-Edge^® Grossing Board
4802	Tissue-Tek^® Accu-Edge^® Grossing Wells
4848	Tissue-Tek^® Accu-Edge^® Grossing Wells, Left-handed
4803	Tissue-Tek^® Accu-Edge^® Grossing Fork, 1.5 mm
4804	Tissue-Tek^® Accu-Edge^® Grossing Fork, 2.0 mm
4807	Tissue-Tek^® Accu-Edge^® Grossing Fork, 2.5 mm
4814	Tissue-Tek^® Accu-Edge^® Cleaning Brushes
4846	Tissue-Tek^® Accu-Edge^® Tamper Set
4847	Tissue-Tek^® Accu-Edge^® Gauge Set
4220	Histo-Tek^® Biopsy Bags, Small
4221	Histo-Tek^® Biopsy Bags, Medium
4223	Tissue-Tek^® Biopsy Bags Small; 1,000/case
4224	Tissue-Tek^® Biopsy Bags Medium; 1,000/case
4785	Tissue-Tek^® Accu-Edge^® Trimming Blades, Short
4786	Tissue-Tek^® Accu-Edge^® Trimming Knife Handle, Short Straight
4789	Tissue-Tek^® Accu-Edge^® Trimming Blades, Long
4790	Tissue-Tek^® Accu-Edge^® Trimming Knife Handle, Long Straight
4791	Tissue-Tek^® Accu-Edge^® Dissecting Scalpel Handle
4792	Tissue-Tek^® Accu-Edge^® Dissecting Scalpel Blades, #61, Curved Tip; 20/case
4793	Tissue-Tek^® Accu-Edge^® Dissecting Scalpel Blades, #62, Pointed Tip; 20/case
6040	Tissue-Tek VIP^® 6 AI Vacuum Infiltration Processor
7090	Tissue-Tek AutoTEC^® a120 Automated Embedder
